A Sunroom is really 10 rooms in one!
The Differences...
Alpha Plus Wall System
*These pictures illustrate features of the Alpha Plus model of wall system. They do not replace instruction guidelines and may be slightly different than your particular installation.
Alpha Plus Framing:
Delivered to you in a modular system
Structural Non Thermal Painted Aluminum
Walls are 3 1/2″ thick
White / Almond framing
Tek Screw heads and required caulking are visible
Alpha Plus Windows:
Our vinyl windows come with a substantial 3 1/2” thick framing, dual cam locks and a variety of glass options to choose from. They come in three different configurations…
Available in White or Almond
Available in fixed or sliding configurations
Vinyl window frames provide up to 1400 times better insulation against extreme heat and cold than aluminum window frames.
Reduces outside noise up to 50% over aluminum window frames
Vinyl frame window sashes allow for smooth operation
DuraLite Glass:
- 1/8” Single Pane Glass
- 1” Sealed Double Pane Clear Glass
- 1” Sealed Double Low E Pane Glass
The OMEGA Wall System
*These pictures illustrate features of the OMEGA model of wall system. They do not replace instruction guidelines and may be slightly different than your particular installation.
OMEGA Framing:
White & Almond framing
Delivered to you in a modular system
Structural Dual Thermal Vinyl Clad Aluminum
Visit our YouTube channel for a demonstration of our vinyl-clad system that stops the cold dead in its tracks! Insulated Sunroom Walls (click)
Walls are a total of 4″ thick
Omega Windows:
Our vinyl windows come with a substantial 3 1/2” thick framing, dual cam locks and a variety of glass options to choose from. They come in three different configurations…
White & Almond window framing
Available in fixed or sliding configurations
Vinyl window frames are up to 1400 times better insulation against extreme heat and cold than aluminum window frames.
Reduces outside noise up to 50% over aluminum window frames
Vinyl window sashes allow for smooth operation
Exclusive vinyl cladding system hides and covers fasteners
Thermally improved system for the ultimate all-season sunroom
DuraLite Glass:
Single Pane Clear Glass (Smart 30)
1” Sealed Double Low E Pane Glass (Smart 60)
1” Sealed Triple Low E Pane Glass (Smart 180)
Approvals & Specifications
I.C.C. Approval (International Conf. of Building Officials) | IRC (International Residential Codes) | IBC (International Building Codes)
CBC (California Building Code) | Meets or Exceeds National Glass Code | Factory Built Housing Approval | C.M.B.S.O.A. Approval (Security Windows)
A-Rated Dual Glass (ALI Laboratories) | U.L. Classified Patented Electrical Raceways | AAMA Approved Windows and Doors
Modular Construction - Easy Installation
A few considerations...
Standard dual sliding windows are available in 36”, 42”, 48”, and 54” widths | All modules require final placement cuts on the jobsite | Modular systems are assembled in a fraction of the time of knock-down assembly systems.
Installation guidelines and support available | Most room sizes can be installed in just 2-4 days | 100% Made in the U.S.A. | List of tools you may need
Life-Time Warranty
- Lifetime Warranty | 20 Year Insulated Glass
- Fully Transferable | Unequalled by any other sunroom
- Incidental Glass Breakage | Warranted as long as you own it!
We Are Here For You!
We have access to all the engineering on all our components so we can help make sure that what you build will last a lifetime! Our people are not commissioned, so there are no sales pressures and no need to ‘upsell’ you on something you actually don’t need. We are simply here to help and get you the DIY materials you need to accomplish your goals!
